The Digital Signal Generator, based on an AVR16EB28, generates a square wave of from 2Hz
to approximately 33.5MHz in precise steps of 2Hz.

The project takes advantage of the new Numerical Controller Oscillator (NCO) mode available in the timer/counter TCF in the AVR EB-series microcontrollers. It uses an AVR16EB28, a crystal, an OLED display, a rotary encoder, a keypad, and a small number of other components.

Introduction

When Microchip released their AVR EB-series chips at the end of 2023 I was intrigued by one particular feature: the timer/counter TCF that works differently from all previous AVR timer/counters. Typically timer/counters divide the clock by a divisor in a compare register. This gives a range of frequencies with unequal steps. For example, with divisors of 1, 2, 3, 4 … a 20MHz clock gives you 20MHz, 10MHz, 6.67MHz, 5MHz … where the steps are getting progressively smaller.

The TCF timer/counter, by comparison, provides a mode called Numerical Controller Oscillator (NCO) which adds a value from a register to the count value on each clock cycle, and takes the output from the overflow ^[1]. For values of 1, 2, 3, 4 … and a 24-bit counter a 20MHz clock gives you frequencies of 1.192Hz, 2.384Hz, 3.576Hz, 4.768Hz … where the steps are equal.

Phase-Locked Loop (PLL)

Another feature of the AVR EB series is a PLL (Phase-Locked Loop) that can be used to multiply a clock of 2.2MHz to 5.5MHz by a factor of 8 or 16 to drive the TCF timer/counter with up to 80MHz, way beyond the processor's maximum 20MHz clock rate. These two features of the AVR EB series led to the idea of this simple wide-range digital signal generator.

Crystal

I wanted to generate frequencies with round numbers of Hz, and better accuracy than the processor's built-in oscillator, so I decided to use a crystal clock. I calculated that the value of crystal clock that would be needed to give round-number frequencies is 2²²Hz or 4.194304MHz, and I was pleased to find that this is a commonly available value.

The NCO oscillator can either produce an asymmetrical square-wave output with a pulse width of one clock cycle, or a symmetrical square wave of half the frequency; I chose the second option.

The frequency range

In this mode the output frequency f  in Hz is given by:

where clk is the clock input to the NCO and inc is the increment value in the compare register. With a crystal of 2²²Hz and a x16 PLL this becomes:

Because inc can take the values 1 to 2²⁴–1 the result is a range of 2Hz to 33554430Hz in steps of exactly 2Hz. For alternative options see Further suggestions below.

Operation

The Digital Signal Generator works as follows: you enter the frequency you want, in Hz, on the numeric keypad as a sequence of up to eight digits, and press *. The display then shows the actual frequency that will be generated, and generates the square waves on the outputs. You can then adjust the frequency up or down in steps of 2Hz using the rotary encoder. Pressing # clears the current input.

The waveform outputs are taken from pins 1 and 28 on the AVR16EB14. For example, here are the two waveforms generated for a frequency of 100000Hz:

Jitter

I should mention one characteristic of the NCO which is that the output will have jitter when the value being added to the counter isn't an exact divisor of the maximum count. For example, with a 24-bit counter and an increment value of 3, which is not an exact divisor of 2²⁴, a 20MHz clock will give a square wave with a wavelength alternating between 0.419 secs and 0.210 secs. However, this is the worst case, and at higher frequencies the jitter rapidly becomes a negligible proportion of the wavelength. Note that, despite the jitter, the average frequency of the output is precise, and so even at low frequencies the jitter is not a problem for applications such as timing or clock generation.

The circuit

Here's the circuit of the Digital Signal Generator:

The circuit of the Digital Signal Generator, based on an AVR16EB28.

The processor

I initially thought about designing the circuit based on a 14-pin AVR16EB14, but this has the limitation that the timer/counter waveform output WO0 is on the same pin as the EXTCLK external clock pin needed for the input to the PLL. A 20-pin package would solve this problem, but I went to the 28-pin AVR16EB28 because it's available in a DIP package, and so could be fitted on the breadboard without needing a breakout board. The extra I/O pins might come in useful in a future expansion. You could of course also use the AVR32EB28.

The display

For the display I used an I2C 128x32 0.91" OLED display, available at low cost from a variety of vendors on AliExpress ^[2]. Note that the display is 3.3V only, so don't power the circuit from 5V.

Numeric keypad

For the numeric keypad I used the PCB keypad I designed in an earlier article; see One-Input Numeric Keypad. It fits neatly on the breadboard, and connects to a single analogue input, PD6. Alternatively you could build the keypad on a piece of Veroboard.

The crystal

The crystal I used is a 4.194304MHz through-hole type with a 0.2" lead spacing, an accuracy of 20ppm, and a load capacitance of 18pF ^[3]. To calculate the capacitor values I used the formula C = 2(C_L - C_S), where C_L is the published load capacitance 18pF, and C_S is the stray capacitance. On a breadboard there is probably close to 18pF of stray capacitance, so additional capacitors are probably not necessary, but if you're designing a PCB version of the circuit you should leave space for the capacitors.

Unlike the earlier ATmega processors the new AVR series don't support an external high-frequency crystal, so it's necessary to provide an external crystal oscillator with its output connected to the EXTCLK input. One possible crystal oscillator design uses an inverter across the crystal:

To avoid the need for an external inverter I used the Event System to construct an inverter as follows:

• Define PC2 as an event output, EVOUTC.
• Define PC3 as an event generator on channel 2
• Configure PC3 to invert the input.

The crystal is connected between PC3 and PC2, and the inverter output PC2 is then connected to the EXTCLK input on PA0.

Rotary encoder

For the rotary encoder I used a Bourns rotary encoder with 16 pulses per rotation ^[4] because the wire terminations fit neatly into a breadboard, but you could use any suitable rotary encoder, such as Adafruit's which includes a knob ^[5].

Construction

I built the whole circuit on a 360 hole breadboard ^[6], using pre-cut colour-coded jumper wires to make the interconnections easier ^[7].

I constructed a right-angle adapter from a 4-way pin header to mount the display horizontally, while plugging it into four consecutive breadboard columns; see the photograph at the start of the article.

The program

Here's a description of the main parts of the program:

Crystal oscillator

The routine SetupCrystal() uses the Event System to configure PC3 and PC2 as an inverter, with the crystal connected across it:

void SetupCrystal () {
  PORTC.EVGENCTRLA = PORT_EVGEN0SEL_PIN3_gc;              // Use PC3 as EVGEN0
  EVSYS.CHANNEL2 = EVSYS_CHANNEL_PORTC_EV0_gc;            // Link EVGEN0 to CHANNEL2
  EVSYS.USEREVSYSEVOUTC = EVSYS_USER_CHANNEL2_gc;         // Link CHANNEL2 to PC2
  PORTC.PIN3CTRL = PORT_INVEN_bm;                         // Invert input PC3
}

The output on PC2 is connected to the input of the Phase-Locked Loop at EXTCLK on PA0.

Phase-Locked Loop (PLL)

The routine SetupPLL() sets up the PLL to multiply the frequency on EXTCLK by 16:

void SetupPLL () {
  uint8_t pllctrla = CLKCTRL_SOURCE_EXTCLK_gc | CLKCTRL_MULFAC_16X_gc;
  _PROTECTED_WRITE(CLKCTRL.PLLCTRLA, pllctrla);           // EXTCLK and x16
}

The built-in macro _PROTECTED_WRITE() must be used because the Clock Controller registers are protected from being changed by a runaway program using Configuration Change Protection.

Numerically Controlled Oscillator (NCO)

The next step is to set up the NCO in the routine SetupNCO(). I found the Microchip application note TB3341 ^[8] helpful in writing this part of the program:

void SetupNCO () {
  PORTMUX.TCFROUTEA = PORTMUX_TCF0_ALT1_gc;               // WO0,WO1 on PA6,PA7

  // Enable WO0 and WO1 and invert WO1 polarity
  while((TCF0.STATUS & TCF_CTRLABUSY_bm) != 0);
  TCF0.CTRLC = TCF_WO0EN_bm | TCF_WO1EN_bm | TCF_WO1POL_bm;

  // Configure NCO Pulse-Frequency mode
  TCF0.CTRLB = TCF_CLKSEL_PLL_gc | TCF_WGMODE_NCOFDC_gc;  // Use PLL as clock
}

This first selects the alternative positions for the waveform outputs WO0 and WO1 because the default positions conflict with EXTCLK.

It then enables the waveform outputs and inverts WO1, to give two out of phase square waves.

Finally it selects NCO Pulse-Frequency mode, which gives a symmetrical square wave, and specifies the PLL as the clock source.

Setting the frequency

The function SetFrequency() is called each time the frequency changes:

void SetFrequency () {
  while((TCF0.STATUS & TCF_CMP0BUSY_bm) != 0);
  TCF0.CMP = Input>>1;
}

Starting and stopping the NCO

Finally, these two functions are called to start and stop the square-wave output:

void StartNCO () {
  while((TCF0.STATUS & TCF_CTRLABUSY_bm) != 0);
  TCF0.CTRLA |= TCF_ENABLE_bm;
}

void StopNCO () {
  while((TCF0.STATUS & TCF_CTRLABUSY_bm) != 0);
  TCF0.CTRLA &= ~TCF_ENABLE_bm;
}

Numeric keypad

The numeric keypad is read by the function ReadKeypad(), which returns the number of the key, or -1 if no key is being pressed. For more details see One-Input Numeric Keypad.

Display driver

The functions for driving the 128x32 OLED display are based on earlier projects. The frequency is plotted using double-sized characters, using smoothing as described in Smooth Big Text.

Rotary encoder

The rotary encoder uses a pin-change interrupt to update the frequency, based on my earlier project Bounce-Free Rotary Encoder.

Main loop

Finally the main loop polls the numeric keypad and updates the display until * is pressed, and then sets the output frequency to the entered value.

Installing the program

First install Spence Konde's DxCore from GitHub: see DxCore - Installation. I used version 1.6.2.

Then, in the Arduino IDE:

• Choose the AVR EB-series (no bootloader) option under the DxCore heading on the Board menu.
• Check that the subsequent options are set as follows (ignore any other options):

Board: "AVR EB-series (no bootloader)"
Chip: "AVR16EB28"
Clock Speed: "20 MHz internal"

You can leave the other options at their defaults, the first option on each submenu.

• Connect a UPDI programmer to the UPDI, GND, and VDD pins.

The recommended way to upload the program is to use a 3.3V Serial board, such as the SparkFun FTDI Basic board ^[9] connected with a Schottky diode as follows. You can substitute a 4.7kΩ resistor for the Schottky diode:

• Set Programmer to the "SerialUPDI - Normal: 230400 baud (recommended)" option.
• Select the USB port corresponding to the USB to Serial board in the Port menu.

• Select Burn Bootloader to reset the fuses (in case they were changed for an earlier project).
• Click Upload to upload the program to the AVR16EB28.

Resources

Here's the program for the Digital Signal Generator: Digital Signal Generator Program.

Get details of the One-Input Numeric Keypad here: One-Input Numeric Keypad.

Further suggestions

• If you prefer an output adjustable in steps of exactly 1Hz you can use the 4.194304MHz crystal divided by 2 to give a range of 1Hz to 16777215Hz in steps of 1Hz, with a symmetrical square-wave output. Note that the AVR EB-series Errata states that in NCO mode the prescaler in TCF0 CTRLA is non-functional, but you can divide the input to the PLL by 2 instead.
• If you want a higher maximum frequency you can change the NCO mode from NCOFDC (fixed duty-cycle) to NCOPF (pulse-frequency) to give a range of 4Hz to 67108860Hz in steps of 4Hz with an asymmetrical square-wave output one clock period wide.
• If your rotary encoder includes a switch you could add a pin-change interrupt on PD2 to toggle between these options, or to change the frequency step size of the rotary encoder.

Updates

7th July 2026: Fixed a problem that meant that the Digital Signal Generator Program source code was password protected.

1. ^ This is like the phase accumulator used in DDS (Direct Digital Synthesis), except that the TCF timer/counter only has a one-bit output.
2. ^ 0.91" 128x32 OLED Display Module White on AliExpress.
3. ^ QCL4.194304F18B23B on Farnell.
4. ^ Bourns Incremental Encoder on Halltronics.
5. ^ Rotary Encoder + Extras on Adafruit.
6. ^ AD-100 Advanced Solderless Breadboard on Rapid Electronics.
7. ^ Jumper Wire Kit on The Pi Hut.
8. ^ Getting Started with Timer/Counter Type F (TCF) on Microchip.
9. ^ SparkFun FTDI Basic Breakout - 3.3V on Sparkfun.

The 12-key Numeric Keypad that interfaces to a single analogue input.

It's on a small 1.2 x 1.6" (30 x 40mm) PCB, and I've also built a demo circuit to show how to use it.

Introduction

Microcontroller projects often need a numeric keypad, and a typical approach is to arrange the keys in a matrix of rows and columns; so for a 3 x 4 numeric keypad you might need to scan seven I/O pins.

This keypad works differently; each key generates a different analogue voltage, and you only need a single analogue input to interface it. I wrote about the idea some time ago in the article One Input Keypad Interface, and I've incorporated keypads using this approach in several projects, such as Walkie-Textie Wireless Communicator and Digital Signal Generator, but I've never published a PCB to allow you to create a stand-alone keypad. However, recently I wanted to prototype a project on a breadboard using a keypad, and I wished I had a PCB version. So here it is.

The circuit

This is the circuit of the keypad:

The circuit of the One-Input Numeric Keypad, which uses a network of six resistors.

The buttons are widely available 6 x 6mm tactile buttons ^[1]. It uses a network of six 0805 surface-mount E6 resistors, arranged as a voltage divider, so each keypress generates a different voltage. It's also designed to draw no current unless a key is pressed. The resistor values are calculated to give the best spread of voltages in the available range from GND to VDD.

The '*' and '#' keys generate the values 10 and 11 respectively; they are useful for functions such as Enter and Delete. The surface-mount resistors are mounted on the back of the board, and the three connections are brought out to a five-way pin header at the top of the board (only three of the pins are used):

The back of the One-Input Numeric Keypad PCB showing the six 0805 surface-mount resistors.

The program

Here's the ReadKeypad() function that interrogates the keypad:

const int Keypad = PIN_PC0;
const int SmallestGap = 40;
int Values[] =  {1023,680,640,590,547,507,464,411,351,273,180,133, 0,-100};
int Buttons[] = {  -1, 11,  9,  6,  3,  0, 10,  8,  7,  5,  4,  2, 1};

int ReadKeypad () {
  int val, lastval=0, count = 0;
  do {
    val = analogRead(Keypad);
    if (abs(val-lastval)<2) count++;
    else { lastval = val; count = 0; }
  } while (count < 3);
  int i = 0;
  val = val - SmallestGap/2;
  while (val < Values[i]) { i++; }
  return Buttons[i - 1];
}

The constant Keypad specifies the analogue input that the keypad is connected to. The program uses two arrays: Values[] stores the analogue values given by each pin, in descending order, and Buttons[] stores the corresponding button for each voltage. The ReadKeypad() routine reads the analogue input, and then checks the value against each value in Values[] until it's larger; it then returns the corresponding button from Buttons[]. If no key is pressed it returns -1.

Demo circuit

I built a simple circuit to demonstrate the keypad by displaying the key pressed on a seven-segment LED display:

The demonstration circuit for the One-Input Numeric Keypad, based on an AVR32EB14,
displays the key pressed on a seven-segment LED display.

I built the demo circuit on a 360 hole breadboard ^[2], using pre-cut colour-coded jumper wires to make the interconnections easier ^[3]. I used an AVR32EB14 in a TSSOP-14 package, mounted on a breakout board ^[4] and a 0.56" single-digit seven-segment display ^[5]. The display is driven directly from the eight I/O pins PA0 to PA1, PC2 to PC3, and PD4 to PD7, with a 220Ω current-limiting resistor from the common cathode to GND. PC0 is used for the analogue keypad input.

Resources

Get Eagle and Gerber files for the keypad: https://github.com/technoblogy/one-input-numeric-keypad.

Or order PCBs from OSH Park here: One-Input Numeric Keypad.

Here's the demo program: One-Input Numeric Keypad Demo.

1. ^ FSM4JH Through-Hole Tactile Switch on Farnell.
2. ^ AD-100 Advanced Solderless Breadboard on Rapid Electronics.
3. ^ Jumper Wire Kit on The Pi Hut.
4. ^ SMT Breakout PCB for SOIC-14 or TSSOP-14 on Adafruit.
5. ^ 0.56" Seven Segment Display on Switch Electronics.
